SPS-M/A Series

DC Power Supply System

The SPS-M/A Series DC Power Supply System supports two series cabinets based on the control mode : SPSM and SPSA. The maximum output voltage and current of a single cabinet is up to 2250V and 3000A respectively. Output power of a single cabinet is up to 180kW. Support master-slave configuration to increase the output capacity to 576kW. SPSM series cabinets use world famous circuit breaker to control the input of each power module inside. After power on, the specified 3U or 6U height power supply will be configured as a Master to control all of the slave units. CSP is the Master in SPSA series cabinets, which is equipped with a PDU (Power Distribution Unit) and a CSP (Control & Supervisory Panel). The PDU consolidate microprocessor and management of hundreds of thousand VA AC mains in a 5U/8U height chassis. The CSP will display the input and output parameters of this system. The touchpanel provides a complete, intuitive user interface for users to easily manage all configuration, setup and update. Full protection designs prevent potential injury.
Product Catalogue Product Video Application Case / Technical Articles Related Download Model Search

Product Features

Large color touch screen, rotary knob and keys provide an excellent operational experience.

Equipped with Emergency Stop, physically off all managed DC power supplies at once.

3-phase input voltage meets worldwide power distribution regulation, AC mains 187~308Vac/340~480Vac for optional.

Constant voltage (CV), constant current (CC) and constant power (CP) operation mode, CC or CV working priority setting.

Standard RS232/RS485/USB interface, optional LAN & GPIB interface, optional CAN interface.

Adjustable voltage/current slew rate.

Smart 3-stage charging algorithm simulation.

Full protection: OVP, OCP, OPP and OTP protection.

Back door with protect switch, safe to the operator.

List/ Step mode programming.

SCPI compatible, provide web GUI function.

Function & Advantage

SPSA Series Advantage


● CSP5/CSP8* , connect with 5/10 units 3U height DC power supply or 2/5 units 6U height DC power supply.

● Built-in power meter, to monitor the AC mains parameters such as V, A, Frequency, Power and PF.

● Support efficiency calculation and electrical quantities recording.

● Built-in Timer, allows to set output running time.

● Easy to enable the output of each power supply from the touch screen, sequence On/Off DC power supplies.

● Display the output parameters of each DC power supply in the same system.

● PDU significantly simplifies the wiring for DC power system.

● User-defined AC input protection parameters such as OVP, UVP, OFP, UFP, OCP and Phase loss.

● Provide web GUI function to monitor & control the CSP via Ethernet.


* Even the same model CSP may be configured differently, which is based on the connected DC power supplies.

Connecting the cabinet


1. The cabinets can be connected in parallel in order to increase output power.

● Maximum 16 units 3U height same model DC power supplies or 6U height same model DC power supplies can be connected via the bus.
● 16 units each with a power of 18kW are connected together to a 288kW system.
● 16 units each with a power of 36kW are connected together to a 576kW system.



2. Different height cabinets can be connected in parallel.

● Use parallel bars to simplify the connection between multiple rack cabinets.
● Realized the gapless connection between multiple rack cabinets.



Displays of CSP

CSP provides below menus which allows user to control and monitor the power supply system via front panel.


Options & Accessories

  • RS-232 communication cable (standard)For RS-232 communication

  • USB communication cable (standard)For USB communication

  • GPIB & LAN card & communication cable (optional)For communication between GPIB and LAN

  • CAN CARD (optional)For CAN communication

  • built-in electronic load (optional)dual quadrant function, this option must be specified when ordering

  • Remote I/O control and monitor card (optional)For external analog control and monitoring

  • Professional version upgrade software (optional)Upgrade version from advanced to professional

Show All

Related downloads

目前在第1页, 共有1页, 共有1条记录 First Prev Next End 跳转到页

Model Search

Search Clear
Model Voltage Current Power Voltage Ripple Control Mode Size
SPSM80VDC54000W-3-18 80V 1800A 54kW <480mVpp, <37.5mVrmsManual Type18U Inquiry
SPSM80VDC90000W-3-24 80V 3000A 90kW <800mVpp, <62.5mVrmsManual Type24U Inquiry
SPSM80VDC108000W-3-30 80V 3000A 108kW <960mVpp, <75mVrmsManual Type30U Inquiry
SPSM80VDC144000W-3-36 80V 3000A 144kW <1280mVpp, <100mVrmsManual Type36U Inquiry
SPSM80VDC180000W-3-42 80V 3000A 180kW <1600mVpp, <125mVrmsManual Type42U Inquiry
SPSA80VDC54000W-3-18 80V 1800A 54kW <480mVpp, <37.5mVrmsAutomatic Type18U Inquiry
SPSA80VDC90000W-3-24 80V 3000A 90kW <800mVpp, <62.5mVrmsAutomatic Type24U Inquiry
SPSA80VDC108000W-3-30 80V 3000A 108kW <960mVpp, <75mVrmsAutomatic Type30U Inquiry
SPSA80VDC144000W-3-36 80V 3000A 144kW <1280mVpp, <100mVrmsAutomatic Type36U Inquiry
SPSA80VDC180000W-3-42 80V 3000A 180kW <1600mVpp, <125mVrmsAutomatic Type42U Inquiry
SPSM165VDC36000W-3-18 165V 540A 36kW <870mVpp, <75mVrmsManual Type18U Inquiry
SPSM165VDC60000W-3-24 165V 900A 60kW <1350mVpp, <125mVrmsManual Type24U Inquiry
SPSM165VDC72000W-3-30 165V 1080A 72kW <1740mVpp, <150mVrmsManual Type30U Inquiry
SPSM165VDC96000W-3-36 165V 1440A 96kW <2320mVpp, <200mVrmsManual Type36U Inquiry
SPSM165VDC120000W-3-42 165V 1800A 120kW <2900mVpp, <250mVrmsManual Type42U Inquiry
SPSA165VDC36000W-3-18 165V 540A 36kW <870mVpp, <75mVrmsAutomatic Type18U Inquiry
SPSA165VDC60000W-3-24 165V 900A 60kW <1350mVpp, <125mVrmsAutomatic Type24U Inquiry
SPSA165VDC72000W-3-30 165V 1080A 72kW <1740mVpp, <150mVrmsAutomatic Type30U Inquiry
SPSA165VDC96000W-3-36 165V 1440A 96kW <2320mVpp, <200mVrmsAutomatic Type36U Inquiry
SPSA165VDC120000W-3-42 165V 1800A 120kW <2900mVpp, <250mVrmsAutomatic Type42U Inquiry
SPSM250VDC54000W-3-18 250V 540A 54kW <825mVpp, <75mVrmsManual Type18U Inquiry
SPSM250VDC90000W-3-24 250V 900A 90kW <2125mVpp, <187.5mVrmsManual Type24U Inquiry
SPSM250VDC108000W-3-30 250V 1080A 108kW <1650mVpp, <150mVrmsManual Type30U Inquiry
SPSM250VDC144000W-3-36 250V 1440A 144kW <2200mVpp, <200mVrmsManual Type36U Inquiry
SPSM250VDC180000W-3-42 250V 1800A 180kW <2750mVpp, <250mVrmsManual Type42U Inquiry
SPSA250VDC54000W-3-18 250V 540A 54kW <825mVpp, <75mVrmsAutomatic Type18U Inquiry
SPSA250VDC90000W-3-24 250V 900A 90kW <2125mVpp, <187.5mVrmsAutomatic Type24U Inquiry
SPSA250VDC108000W-3-30 250V 1080A 108kW <1650mVpp, <150mVrmsAutomatic Type30U Inquiry
SPSA250VDC144000W-3-36 250V 1440A 144kW <2200mVpp, <200mVrmsAutomatic Type36U Inquiry
SPSA250VDC180000W-3-42 250V 1800A 180kW <2750mVpp, <250mVrmsAutomatic Type42U Inquiry
SPSM360VDC54000W-3-18 360V 382.5A 54kW <480mVpp, <82.5mVrmsManual Type18U Inquiry
SPSM360VDC90000W-3-24 360V 637.5A 90kW <800mVpp, <137.5mVrmsManual Type24U Inquiry
SPSM360VDC108000W-3-30 360V 765A 108kW <960mVpp, <165mVrmsManual Type30U Inquiry
SPSM360VDC144000W-3-36 360V 1020A 144kW <1280mVpp, <220mVrmsManual Type36U Inquiry
SPSM360VDC180000W-3-42 360V 1275A 180kW <1600mVpp, <275mVrmsManual Type42U Inquiry
SPSA360VDC54000W-3-18 360V 382.5A 54kW <480mVpp, <82.5mVrmsAutomatic Type18U Inquiry
SPSA360VDC90000W-3-24 360V 637.5A 90kW <800mVpp, <137.5mVrmsAutomatic Type24U Inquiry
SPSA360VDC108000W-3-30 360V 765A 108kW <960mVpp, <165mVrmsAutomatic Type30U Inquiry
SPSA360VDC144000W-3-36 360V 1020A 144kW <1280mVpp, <220mVrmsAutomatic Type36U Inquiry
SPSA360VDC180000W-3-42 360V 1275A 180kW <1600mVpp, <275mVrmsAutomatic Type42U Inquiry
SPSM500VDC54000W-3-18 500V 288A 54kW <975mVpp, <240mVrmsManual Type18U Inquiry
SPSM500VDC90000W-3-24 500V 480A 90kW <1625mVpp, <400mVrmsManual Type24U Inquiry
SPSM500VDC108000W-3-30 500V 576A 108kW <1950mVpp, <480mVrmsManual Type30U Inquiry
SPSM500VDC144000W-3-36 500V 768A 144kW <2600mVpp, <640mVrmsManual Type36U Inquiry
SPSM500VDC180000W-3-42 500V 960A 180kW <3250mVpp, <800mVrmsManual Type42U Inquiry
SPSA500VDC54000W-3-18 500V 288A 54kW <975mVpp, <240mVrmsAutomatic Type18U Inquiry
SPSA500VDC90000W-3-24 500V 480A 90kW <1625mVpp, <400mVrmsAutomatic Type24U Inquiry
SPSA500VDC108000W-3-30 500V 576A 108kW <1950mVpp, <480mVrmsAutomatic Type30U Inquiry
SPSA500VDC144000W-3-36 500V 768A 144kW <2600mVpp, <640mVrmsAutomatic Type36U Inquiry
SPSA500VDC180000W-3-42 500V 960A 180kW <3250mVpp, <800mVrmsAutomatic Type42U Inquiry
SPSM750VDC54000W-3-18 750V 189A 54kW <1500mVpp, <375mVrmsManual Type18U Inquiry
SPSM750VDC90000W-3-24 750V 315A 90kW <2500mVpp, <625mVrmsManual Type24U Inquiry
SPSM750VDC108000W-3-30 750V 378A 108kW <3000mVpp, <750mVrmsManual Type30U Inquiry
SPSM750VDC144000W-3-36 750V 504A 144kW <4000mVpp, <1000mVrmsManual Type36U Inquiry
SPSM750VDC180000W-3-42 750V 630A 180kW <5000mVpp, <1250mVrmsManual Type42U Inquiry
SPSA750VDC54000W-3-18 750V 189A 54kW <1500mVpp, <375mVrmsAutomatic Type18U Inquiry
SPSA750VDC90000W-3-24 750V 315A 90kW <2500mVpp, <625mVrmsAutomatic Type24U Inquiry
SPSA750VDC108000W-3-30 750V 378A 108kW <3000mVpp, <750mVrmsAutomatic Type30U Inquiry
SPSA750VDC144000W-3-36 750V 504A 144kW <4000mVpp, <1000mVrmsAutomatic Type36U Inquiry
SPSA750VDC180000W-3-42 750V 630A 180kW <5000mVpp, <1250mVrmsAutomatic Type42U Inquiry
SPSM1000VDC36000W-3-18 1000V 96A 36kW <2250mVpp, <480mVrmsManual Type18U Inquiry
SPSM1000VDC60000W-3-24 1000V 160A 60kW <3750mVpp, <800mVrmsManual Type24U Inquiry
SPSM1000VDC72000W-3-30 1000V 192A 72kW <4500mVpp, <960mVrmsManual Type30U Inquiry
SPSM1000VDC96000W-3-36 1000V 256A 96kW <6000mVpp, <1280mVrmsManual Type36U Inquiry
SPSM1000VDC120000W-3-42 1000V 320A 120kW <7500mVpp, <1600mVrmsManual Type42U Inquiry
SPSA1000VDC36000W-3-18 1000V 96A 36kW <2250mVpp, <480mVrmsAutomatic Type18U Inquiry
SPSA1000VDC60000W-3-24 1000V 160A 60kW <3750mVpp, <800mVrmsAutomatic Type24U Inquiry
SPSA1000VDC72000W-3-30 1000V 192A 72kW <4500mVpp, <960mVrmsAutomatic Type30U Inquiry
SPSA1000VDC96000W-3-36 1000V 256A 96kW <6000mVpp, <1280mVrmsAutomatic Type36U Inquiry
SPSA1000VDC120000W-3-42 1000V 320A 120kW <7500mVpp, <1600mVrmsAutomatic Type42U Inquiry
SPSM1500VDC54000W-3-18 1500V 96A 54kW <2925mVpp, <975mVrmsManual Type18U Inquiry
SPSM1500VDC90000W-3-24 1500V 160A 90kW <4875mVpp, <1625mVrmsManual Type24U Inquiry
SPSM1500VDC108000W-3-30 1500V 192A 108kW <5850mVpp, <1950mVrmsManual Type30U Inquiry
SPSM1500VDC144000W-3-36 1500V 256A 144kW <7800mVpp, <2600mVrmsManual Type36U Inquiry
SPSM1500VDC180000W-3-42 1500V 320A 180kW <9750mVpp, <3250mVrmsManual Type42U Inquiry
SPSA1500VDC54000W-3-18 1500V 96A 54kW <2925mVpp, <975mVrmsAutomatic Type18U Inquiry
SPSA1500VDC90000W-3-24 1500V 160A 90kW <4875mVpp, <1625mVrmsAutomatic Type24U Inquiry
SPSA1500VDC108000W-3-30 1500V 192A 108kW <5850mVpp, <1950mVrmsAutomatic Type30U Inquiry
SPSA1500VDC144000W-3-36 1500V 256A 144kW <7800mVpp, <2600mVrmsAutomatic Type36U Inquiry
SPSA1500VDC180000W-3-42 1500V 320A 180kW <9750mVpp, <3250mVrmsAutomatic Type42U Inquiry
SPSM2250VDC54000W-3-18 2250V 63A 54kW <4800mVpp, <1125mVrmsManual Type18U Inquiry
SPSM2250VDC90000W-3-24 2250V 105A 90kW <8000mVpp, <1875mVrmsManual Type24U Inquiry
SPSM2250VDC108000W-3-30 2250V 126A 108kW <9600mVpp, <2250mVrmsManual Type30U Inquiry
SPSM2250VDC144000W-3-36 2250V 168A 144kW <12800mVpp, <3000mVrmsManual Type36U Inquiry
SPSM2250VDC180000W-3-42 2250V 210A 180kW <16000mVpp, <3750mVrmsManual Type42U Inquiry
SPSA2250VDC54000W-3-18 2250V 63A 54kW <4800mVpp, <1125mVrmsAutomatic Type18U Inquiry
SPSA2250VDC90000W-3-24 2250V 105A 90kW <8000mVpp, <1875mVrmsAutomatic Type24U Inquiry
SPSA2250VDC108000W-3-30 2250V 126A 108kW <9600mVpp, <2250mVrmsAutomatic Type30U Inquiry
SPSA2250VDC144000W-3-36 2250V 168A 144kW <12800mVpp, <3000mVrmsAutomatic Type36U Inquiry
SPSA2250VDC180000W-3-42 2250V 210A 180kW <16000mVpp, <3750mVrmsAutomatic Type42U Inquiry
